This is a small rear pivot guard designed for use on lathes with chuck sizes up to 200mm diameter. Its simple cast aluminum L shape with polycarbonate windows allows positioning of the rear pivot shaft and mounting either vertically or towards or away from the front of the lathe headstock to suit the size of the chuck.   Available with or without an interlock micro switch but generally supplied in Australia and NZ with a 2NC micro switch. This guard is available with or without the side skirt illustrated. Guard has adjustable stops to enable radial positioning in the closed position and the mounting bracket has fixing holes for either vertical or horizontal screw fixing.



MODEL	Chuck Diameter	Width	Top length	Front length
L6	150 – 200mm	175mm	175mm	175mm
